LPX-50 Gear Bending Fatigue Testing Machine

Gear bending fatigue testing machine is used to test the fatigue fracture resistance of various metal materials

Introduction

Gear bending fatigue testing machine is used to test the fatigue fracture resistance of various metal materials and draw S-N curves; Equipped with different fixtures or environmental experimental devices, it is widely used to test the fatigue life of various materials and components (such as plates, gears, crankshafts, bolts, chains, connecting rods, compact stretching, etc.).

Parameters

No.	Parameter Item	Specification
1	Max. Static Test Force (kN)	50
2	Max. Dynamic Test Force (Peak, kN)	25
3	Test Force Measurement Range	4% FS - 100% FS
4	Test Force Resolution	±1/100000
5	Static Force Indication Error	≤ ±1%
6	Dynamic Force Indication Error	≤ ±2%
7	Fluctuation of Mean/Alternating Test Force	≤ ±0.5% FS
8	Test Frequency Range (Hz)	60 - 300
9	Max. Counting Range	≥ 9×10⁹
10	Test Space (mm)	500
11	Test Width (mm)	420
12	Operation Mode	Touch screen and testing software (Dual display & control)
13	Host Weight (kg)	2000
14	Overall Dimensions (W x D x H) (mm)	Approx. 650 x 600 x 2500
15	Power Supply	220V, 1.5kW
